Automating RDP Connection Testing with PowerShell and PsExec

Streamline Your Server Access Verification Process Efficiently

Key Takeaways

Comprehensive Automation: Utilize PowerShell and PsExec to automate RDP connection tests across multiple servers.
Security Best Practices: Ensure secure handling of credentials and compliance with organizational policies.
Detailed Reporting: Generate logs and reports to track the success and failure of connection attempts.

Introduction

In a complex Active Directory (AD) environment with multiple server types such as domain controllers and file servers, managing and verifying access permissions is crucial. Automating the process of testing Remote Desktop Protocol (RDP) connectivity using different AD accounts, like Tier 1 and Tier 2, can significantly enhance efficiency and accuracy. This guide provides a comprehensive approach to automating RDP connection testing using PowerShell and PsExec, ensuring both effectiveness and adherence to security best practices.

Prerequisites

Administrative Privileges: Ensure you have the necessary permissions to execute scripts and access the servers.
PowerShell: A suitable version of PowerShell installed on your system.
PsExec: Downloaded from the official Microsoft Sysinternals website and placed in an accessible directory.
Server List: A text file (e.g., servers.txt) containing the IP addresses or hostnames of the target servers, one per line.
Secure Credential Storage: Implement methods to securely store and retrieve credentials, avoiding plaintext storage.

Step-by-Step Guide

1. Preparing the Server List

Create a text file named servers.txt that includes all the server IP addresses or hostnames you wish to test. Ensure each entry is on a separate line. For example:


192.168.1.10
192.168.1.20
file-server01
domain-controller02

2. Installing PsExec

PsExec is a powerful tool from Microsoft Sysinternals that allows you to execute processes on remote systems. Follow these steps to install PsExec:

Download PsExec from the official Microsoft Sysinternals website.
Extract the downloaded files and place PsExec.exe in a directory that's included in your system’s PATH environment variable, or note its full path for use in scripts.

3. Securing Credentials

It's critical to handle credentials securely to prevent unauthorized access. Avoid hardcoding credentials in scripts. Instead, use PowerShell's Get-Credential cmdlet or store credentials in a secure encrypted file or a credential vault.

Example using Get-Credential:


$credential = Get-Credential -Message "Enter your Tier 1 account credentials"

4. Writing the PowerShell Script

Create a PowerShell script (e.g., Test-RDPConnection.ps1) that automates the process of testing RDP connections using PsExec. Below is a comprehensive script with detailed explanations:


# Define the path to PsExec
$psexecPath = "C:\Path\To\PsExec.exe"

# Import the list of servers
$servers = Get-Content -Path "C:\Path\To\servers.txt"

# Prompt for Tier 1 credentials securely
$credential = Get-Credential -Message "Enter your Tier 1 account credentials"

# Define the log file path
$logFile = "C:\Path\To\RDP_Test_Results.csv"

# Initialize the log file with headers
"Server,ConnectionStatus,Timestamp" | Out-File -FilePath $logFile -Encoding UTF8

# Function to test RDP connection using PsExec
function Test-RDPConnection {
    param (
        [string]$ComputerName,
        [System.Management.Automation.PSCredential]$Credential
    )

    $username = $Credential.UserName
    $password = $Credential.GetNetworkCredential().Password

    try {
        # Construct the PsExec command
        $command = "& `"$psexecPath`" \\$ComputerName -u $username -p $password cmd /c echo RDP connection successful"

        # Execute the command
        $result = Invoke-Expression $command

        # Determine the connection status based on the output
        if ($result -like "*RDP connection successful*") {
            $status = "Success"
        } else {
            $status = "Failed"
        }
    }
    catch {
        $status = "Error: $_"
    }

    # Log the result with a timestamp
    "$ComputerName,$status,$(Get-Date -Format 'yyyy-MM-dd HH:mm:ss')" | Out-File -FilePath $logFile -Append -Encoding UTF8

    # Output to console
    Write-Host "$ComputerName - $status" -ForegroundColor ($status -eq "Success" ? "Green" : "Red")
}

# Iterate through each server and test RDP connection
foreach ($server in $servers) {
    Test-RDPConnection -ComputerName $server -Credential $credential
}

Write-Host "RDP connection tests completed. Results are saved in $logFile" -ForegroundColor Cyan

Script Breakdown

Path Definition: Specify the full path to the PsExec.exe file.
Server Import: Load the list of servers from servers.txt.
Credential Prompt: Securely prompt for Tier 1 account credentials using Get-Credential.
Logging Setup: Initialize a CSV log file to record the results.
Function Definition: Define a function Test-RDPConnection that uses PsExec to attempt an RDP connection and logs the outcome.
Execution Loop: Iterate through each server in the list and invoke the connection test.
Completion Message: Notify the user upon completion of the tests.

5. Running the Script

Follow these steps to execute the script:

Save the PowerShell script as Test-RDPConnection.ps1.
Open PowerShell with administrative privileges.
Navigate to the directory containing the script.
Execute the script using the following command:


.\Test-RDPConnection.ps1

When prompted, enter the Tier 1 account credentials. The script will then attempt to connect to each server and log the results.

6. Reviewing the Results

The script generates a CSV file (RDP_Test_Results.csv) containing the following columns:

Server: The hostname or IP address of the server.
ConnectionStatus: Indicates whether the RDP connection was successful, failed, or encountered an error.
Timestamp: The date and time when the test was executed.

You can open this CSV file using Microsoft Excel or any other spreadsheet application to analyze the results.

Enhancing the Script for Advanced Automation

Implementing Parallel Processing

To speed up the testing process, especially in environments with a large number of servers, you can leverage PowerShell's parallel processing capabilities using ForEach-Object -Parallel or the Start-Job cmdlet.

Example using parallel processing:


$servers = Get-Content -Path "C:\Path\To\servers.txt"
$credential = Get-Credential -Message "Enter your Tier 1 account credentials"
$logFile = "C:\Path\To\RDP_Test_Results.csv"

"Server,ConnectionStatus,Timestamp" | Out-File -FilePath $logFile -Encoding UTF8

$servers | ForEach-Object -Parallel {
    param ($server, $psexecPath, $credential, $logFile)

    $username = $credential.UserName
    $password = $credential.GetNetworkCredential().Password

    try {
        $command = "& `"$psexecPath`" \\$server -u $username -p $password cmd /c echo RDP connection successful"
        $result = Invoke-Expression $command

        if ($result -like "*RDP connection successful*") {
            $status = "Success"
        } else {
            $status = "Failed"
        }
    }
    catch {
        $status = "Error: $_"
    }

    "$server,$status,$(Get-Date -Format 'yyyy-MM-dd HH:mm:ss')" | Out-File -FilePath $logFile -Append -Encoding UTF8
    Write-Host "$server - $status" -ForegroundColor ($status -eq "Success" ? "Green" : "Red")
} -ArgumentList $_, $psexecPath, $credential, $logFile

Scheduling Automated Tests

To regularly perform RDP connection tests without manual intervention, you can schedule the PowerShell script using Windows Task Scheduler.

Open Task Scheduler and create a new task.
Configure the trigger to specify when the task should run (e.g., daily, weekly).
Set the action to start a program with the following settings:
- Program/script: powershell.exe
- Arguments: -File "C:\Path\To\Test-RDPConnection.ps1"
Configure the task to run with the highest privileges and ensure it runs under an account with the necessary permissions.
Save the task. It will now execute the script based on the defined schedule.

Integrating with Monitoring Systems

For enhanced visibility and alerting, integrate the RDP connection test results with your organization's monitoring and alerting systems. This can be achieved by:

Sending Alerts: Configure the script to send email notifications or integrate with Slack, Microsoft Teams, or other communication tools when connections fail.
Dashboards: Import the CSV results into monitoring dashboards like Power BI, Grafana, or your SIEM for real-time visualization.

Example: Sending Email Notifications

Modify the script to send an email if any RDP connection fails:


# Define SMTP server details
$smtpServer = "smtp.yourdomain.com"
$from = "admin@yourdomain.com"
$to = "security@yourdomain.com"
$subject = "RDP Connection Test Alert"

# After testing all servers
$failedConnections = Import-Csv -Path $logFile | Where-Object { $_.ConnectionStatus -ne "Success" }

if ($failedConnections) {
    $body = "The following servers failed the RDP connection test:`n"
    foreach ($entry in $failedConnections) {
        $body += "$($entry.Server) - Status: $($entry.ConnectionStatus) - Time: $($entry.Timestamp)`n"
    }

    Send-MailMessage -SmtpServer $smtpServer -From $from -To $to -Subject $subject -Body $body
    Write-Host "Alert email sent for failed connections." -ForegroundColor Yellow
}

Security Considerations

When automating RDP connection tests, it's essential to adhere to security best practices to protect sensitive information and maintain compliance:

Credential Management: Use secure methods to handle credentials, such as encrypted password storage or credential management systems.
Least Privilege Principle: Ensure that the Tier 1 account used for testing has only the necessary permissions required for the task.
Audit and Logging: Maintain detailed logs of all connection attempts and regularly review them for any suspicious activity.
Network Security: Ensure that the ports required for RDP and PsExec are appropriately secured and monitored.
Compliance: Follow organizational policies and regulatory requirements related to remote access and automation scripts.

Troubleshooting

Encountering issues during automation is common. Here are some troubleshooting steps to resolve common problems:

PsExec Execution Issues:
- Verify that PsExec is installed correctly and the path is accurate.
- Ensure that the account used has the necessary permissions to execute remote commands.
- Check for firewall rules that may be blocking PsExec or RDP traffic.
Credential Errors:
- Ensure that the credentials entered are correct and have not expired.
- Check if the account has the necessary rights to access the target servers.
Script Execution Policies:
- If encountering execution policy errors, you may need to adjust the PowerShell execution policy using the Set-ExecutionPolicy cmdlet.
- Example: Set-ExecutionPolicy RemoteSigned
Network Connectivity:
- Ensure that the target servers are reachable from the testing machine.
- Use Test-NetConnection to verify connectivity on port 3389 for RDP.

Conclusion

Automating RDP connection testing using PowerShell and PsExec offers a robust solution for verifying access permissions across multiple servers in an AD environment. By following the steps outlined in this guide, you can enhance operational efficiency, maintain security compliance, and ensure that your Tier 1 accounts function as intended. Remember to continuously monitor and refine your scripts to adapt to evolving security landscapes and organizational needs.
