Resolving Sorting Issues in Springdoc OpenAPI Documentation

When working with Spring Boot applications, Springdoc OpenAPI is a powerful tool for automatically generating comprehensive API documentation. However, developers occasionally encounter challenges, such as sorting API documentation not functioning as expected. This guide delves into the common pitfalls and provides detailed solutions to ensure your API documentation is organized precisely as intended.

Understanding the Issue

In the context of Springdoc OpenAPI, sorting issues typically revolve around the order in which API tags and operations (endpoints) appear in the Swagger UI. Proper sorting enhances the readability and navigability of the API documentation, making it easier for users to find and understand different API sections.

The specific problem addressed here involves the use of the @ApiSupport(order = 4) annotation, which does not seem to influence the sorting of API documentation as expected. The user has configured Springdoc properties in their application.yml and annotated their controller with @ApiSupport and @Tag, but the desired sorting remains ineffective.

Key Components and Annotations

1. Springdoc OpenAPI

Springdoc OpenAPI is a library that automates the generation of OpenAPI 3.0 documentation for Spring Boot projects. It seamlessly integrates with Swagger UI, providing an interactive interface for API exploration.

2. Annotations

• @Tag: Defines metadata for API tags, including name and description.
• @ApiSupport: An annotation specific to Knife4j, an enhanced version of Swagger UI, used to influence the order of API documentation sections.

Common Causes for Sorting Issues

1. Misplacement or Incorrect Use of Annotations

The @ApiSupport annotation is not a native part of Springdoc OpenAPI; it belongs to Knife4j. Using it without integrating Knife4j properly can lead to unexpected behaviors, such as ineffective sorting.

2. Missing or Incompatible Dependencies

Using annotations from Knife4j without including the necessary Knife4j dependencies in your project can prevent those annotations from functioning correctly. Additionally, version incompatibilities between Springdoc OpenAPI and Knife4j can cause features to break.

3. Incorrect Configuration Properties

Springdoc provides specific properties like tags-sorter and operations-sorter to control the sorting behavior. Misconfiguring these properties or omitting them entirely can result in default sorting that may not align with your requirements.

Solutions and Best Practices

1. Ensure Proper Use of Annotations

If you intend to use @ApiSupport, it should be accompanied by the appropriate Knife4j dependencies. However, if you prefer to stick with Springdoc OpenAPI's native features, consider removing @ApiSupport and leveraging Springdoc's own annotations and configurations for sorting.

2. Configure Springdoc Properties Correctly

Springdoc allows you to control the sorting of tags and operations through configuration properties. Ensure these are set correctly in your application.yml or application.properties file.

Example Configuration:

springdoc:
  api-docs:
    enabled: true
    path: /v3/api-docs
  swagger-ui:
    path: /api
    tags-sorter: alpha        # Options: 'alpha', 'definition', or 'none'
    operations-sorter: alpha  # Options: 'alpha', 'method', or 'none'
  default-flat-param-object: true


Property Descriptions:

• tags-sorter: Defines the sorting strategy for API tags.
  • alpha: Sorts tags alphabetically.
  • definition: Sorts tags based on their definition order.
  • none: Disables sorting; tags appear in the order they are defined.
• operations-sorter: Defines the sorting strategy for API operations within each tag.
  • alpha: Sorts operations alphabetically by their operation IDs.
  • method: Sorts operations based on HTTP methods (e.g., GET, POST).
  • none: Disables sorting; operations appear in the order they are defined.

3. Implement Custom Sorting with OpenApiCustomizer

When built-in sorting configurations do not meet specific requirements, implementing a custom sorting mechanism using the OpenApiCustomizer interface can provide finer control over the ordering of tags and operations.

Example Implementation in Java:

import io.swagger.v3.oas.models.OpenAPI;
import io.swagger.v3.oas.models.tags.Tag;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springdoc.core.customizers.OpenApiCustomizer;

import java.util.Comparator;
import java.util.List;

@Configuration
public class OpenAPIConfig {

    @Bean
    public OpenApiCustomizer sortTagsCustomizer() {
        return openApi -> {
            List tags = openApi.getTags();
            tags.sort(Comparator.comparing(Tag::getName));
            openApi.setTags(tags);
        };
    }
}


This example sorts the tags alphabetically. You can modify the comparator to implement custom sorting logic based on your specific needs.

4. Verify and Update Dependencies

Ensure that all necessary dependencies are included in your project and that their versions are compatible. If you intend to use Knife4j features like @ApiSupport, include the Knife4j dependencies appropriately.

For Springdoc OpenAPI:

<dependency>
    <groupId>org.springdoc</groupId>
    <artifactId>springdoc-openapi-ui</artifactId>
    <version>2.1.0</version> <!-- Use the latest stable version -->
</dependency>


If Using Knife4j:

<dependency>
    <groupId>com.github.xiaoymin</groupId>
    <artifactId>knife4j-springdoc-ui</artifactId>
    <version>4.0.0</version> <!-- Ensure compatibility with Springdoc version -->
</dependency>


Refer to the Springdoc GitHub Repository and the Knife4j GitHub Repository for the latest versions and compatibility information.

5. Clear Caches and Rebuild the Project

Sometimes, outdated configurations or cached data can prevent new settings from taking effect. Clearing the build directories and rebuilding the project can resolve such issues.

Steps to Clear Cache:

• Delete the /target or /build directories.
• For Maven projects, run mvn clean install.
• For Gradle projects, run ./gradlew clean build.
• Redeploy the application.

6. Inspect the Generated OpenAPI Specification

Validating the generated OpenAPI JSON can provide insights into whether the tags and operations are ordered correctly.

Steps to Inspect:

1. Start your Spring Boot application.
2. Navigate to http://localhost:8080/v3/api-docs (adjust the port if necessary).
3. Examine the tags array to verify the order.

If discrepancies are found between the expected and actual order, revisit the configuration and customization steps outlined above.

Example Configuration and Controller Setup

application.yml

springdoc:
  api-docs:
    enabled: true
    path: /v3/api-docs
  swagger-ui:
    path: /api
    tags-sorter: alpha        # Sort tags alphabetically
    operations-sorter: alpha  # Sort operations alphabetically
  default-flat-param-object: true


Controller Example Without Knife4j

import org.springframework.web.bind.annotation.RestController;
import org.springframework.web.bind.annotation.RequestMapping;
import io.swagger.v3.oas.annotations.tags.Tag;

@RestController
@RequestMapping("/bear")
@Tag(name = "主体管理_地块管理", description = "主体管理_地块管理")
public class BearController {

    // Define your API endpoints here
}


In this setup, the controller is annotated with @Tag to define its API section. The sorting is handled by the tags-sorter and operations-sorter properties in the configuration.

Controller Example With Knife4j

import org.springframework.web.bind.annotation.RestController;
import org.springframework.web.bind.annotation.RequestMapping;
import io.swagger.v3.oas.annotations.tags.Tag;
import com.github.xiaoymin.knife4j.annotations.ApiSupport;

@RestController
@RequestMapping("/bear")
@ApiSupport(order = 4)  // Specific to Knife4j
@Tag(name = "主体管理_地块管理", description = "主体管理_地块管理")
public class BearController {

    // Define your API endpoints here
}


If you choose to use Knife4j, ensure that the @ApiSupport annotation is recognized by including the necessary Knife4j dependencies and configurations.

Integrating Knife4j for Enhanced Features

Knife4j extends the capabilities of Swagger UI by providing advanced features, including improved sorting and grouping functionalities. If enhanced control over API documentation is required beyond what Springdoc offers, integrating Knife4j can be beneficial.

Steps to Integrate Knife4j

1. Add Knife4j Dependency:


   <dependency>
       <groupId>com.github.xiaoymin</groupId>
       <artifactId>knife4j-springdoc-ui</artifactId>
       <version>4.0.0</version> <!-- Ensure compatibility with Springdoc version -->
   </dependency>


2. Configure Knife4j Properties:


   knife4j:
     enable: true
   springdoc:
     swagger-ui:
       tags-sorter: alpha
       operations-sorter: custom


   This configuration enables Knife4j and adjusts sorting strategies accordingly.

3. Use Knife4j Annotations:

   Ensure that annotations like @ApiSupport(order = 4) are used appropriately within your controllers to influence sorting.

Refer to the Knife4j Documentation for detailed setup and configuration guidelines.

Comprehensive Example Configuration

application.yml with Knife4j

springdoc:
  api-docs:
    enabled: true
    path: /v3/api-docs
  swagger-ui:
    enabled: true
    tags-sorter: definition
    operations-sorter: method
  default-flat-param-object: true

knife4j:
  enable: true
  documentation:
    swagger-ui:
      operations-sorter: method
      tags-sorter: custom


Controller Example with Knife4j Annotations

import org.springframework.web.bind.annotation.RestController;
import org.springframework.web.bind.annotation.RequestMapping;
import io.swagger.v3.oas.annotations.tags.Tag;
import com.github.xiaoymin.knife4j.annotations.ApiSupport;

@RestController
@RequestMapping("/bear")
@ApiSupport(order = 4) // Specific to Knife4j
@Tag(name = "主体管理_地块管理", description = "主体管理_地块管理")
public class BearController {

    // Define your API endpoints here
}


In this configuration:

• Springdoc OpenAPI is configured to enable API docs and Swagger UI.
• Knife4j is enabled to extend Swagger UI functionalities.
• The @ApiSupport(order = 4) annotation is used to influence the sorting order within Knife4j's enhanced interface.

Additional Troubleshooting Steps

1. Verify Annotation Placement

Ensure that annotations like @ApiSupport and @Tag are placed at the class level of your controllers, not at the method level. Incorrect placement can prevent them from having the intended effect.

2. Check for Caching Issues

Sometimes, build tool caching can retain outdated configurations. Clearing caches and performing a fresh build can help apply the latest configurations effectively.

3. Review OpenAPI Extensions

Using OpenAPI extensions can provide additional metadata to influence documentation behavior. For example, adding an x-order extension to tags can help in custom sorting scenarios.

Example:

import io.swagger.v3.oas.models.OpenAPI;
import io.swagger.v3.oas.models.tags.Tag;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springdoc.core.customizers.OpenApiCustomizer;

import java.util.Arrays;
import java.util.Map;

@Configuration
public class OpenAPIConfig {

    @Bean
    public OpenApiCustomizer customTagOrder() {
        return openApi -> {
            openApi.setTags(Arrays.asList(
                new Tag().name("主体管理_地块管理")
                         .description("主体管理_地块管理")
                         .addExtension("x-order", 4)
            ));
        };
    }
}


This extension can then be utilized within your custom UI configurations to respect the defined order.

Conclusion

Sorting API documentation effectively in Springdoc OpenAPI requires a clear understanding of the annotations and configurations at your disposal. Whether leveraging Springdoc's native properties or integrating tools like Knife4j for enhanced features, following best practices ensures that your API documentation remains organized and user-friendly.

By:

• Ensuring correct annotation usage and placement.
• Configuring Springdoc properties accurately.
• Implementing custom sorting logic when necessary.
• Verifying and updating dependencies to maintain compatibility.
• Utilizing advanced tools like Knife4j for extended functionalities.

You can overcome sorting challenges and maintain high-quality, navigable API documentation that effectively serves your development and user communities.
