Maximizing Real-Time Performance on Ubuntu with Intel CPUs

Comprehensive Strategies to Optimize Your System for Real-Time Applications

---

Key Takeaways

• Implement a Real-Time Kernel: Utilize the PREEMPT_RT patch or Ubuntu’s low-latency kernel to achieve deterministic performance.
• Optimize CPU and Power Settings: Configure CPU governors, disable power-saving features, and isolate CPU cores for real-time tasks.
• Fine-Tune System Parameters: Adjust kernel parameters, manage IRQ handling, and disable unnecessary services to minimize latency.

---

1. Implementing a Real-Time Kernel

Enhancing Kernel for Deterministic Performance

To achieve minimal latency and predictable performance essential for real-time applications, it is crucial to use a real-time optimized kernel. The PREEMPT_RT patch transforms the standard Linux kernel into a real-time kernel by enabling full preemption and reducing interrupt handling delays.

Steps to Install a Real-Time Kernel

Ubuntu provides options to install low-latency or real-time kernels, typically available through Ubuntu Pro subscriptions. Alternatively, users can compile their own kernel with the PREEMPT_RT patch enabled.

sudo apt-get update
sudo apt-get install linux-image-rt-amd64
sudo reboot


After installation, verify the active kernel version to ensure the real-time kernel is in use.

2. Optimizing CPU and Power Settings

Configuring CPU Governors and Managing Power States

CPU Governor Configuration

Setting the CPU governor to 'performance' ensures that the CPU operates at its maximum frequency, reducing latency and enhancing responsiveness. This can be done using the cpufrequtils package.

sudo apt-get install cpufrequtils
sudo cpufreq-set -g performance


Alternatively, you can set the governor by writing directly to the scaling governor file:

echo performance | sudo tee /sys/devices/system/cpu/cpu*/cpufreq/scaling_governor


Disabling Power-Saving Features

Power-saving features like C-states and dynamic frequency scaling can introduce latency. Disabling these features can lead to more consistent performance.

Add the following parameters to the GRUB configuration to disable C-states:

sudo nano /etc/default/grub


Modify the GRUB_CMDLINE_LINUX_DEFAULT line:

GRUB_CMDLINE_LINUX_DEFAULT="quiet splash intel_idle.max_cstate=0 processor.max_cstate=0 idle=poll"


sudo update-grub
sudo reboot


Disabling Turbo Boost can also be beneficial if consistent CPU performance is critical. This can typically be done through the BIOS/UEFI settings.

Isolating CPU Cores

Isolating specific CPU cores for real-time tasks prevents other system processes from interfering, thereby reducing latency. This is achieved by adding the isolcpus parameter to the GRUB configuration.

sudo nano /etc/default/grub


Add isolcpus=0-3 (adjust based on your CPU cores) to the GRUB_CMDLINE_LINUX_DEFAULT line:

GRUB_CMDLINE_LINUX_DEFAULT="quiet splash isolcpus=0-3"


sudo update-grub
sudo reboot


3. Fine-Tuning System Parameters

Adjusting Kernel and System Settings for Optimal Performance

Kernel Parameter Adjustments

Using sysctl to modify kernel parameters can help in reducing latency and improving performance.

sudo sysctl -w vm.swappiness=10
sudo sysctl -w kernel.sched_rt_runtime_us=950000


These settings reduce the tendency to swap memory to disk and increase the runtime allocated to real-time tasks.

IRQ Handling and Affinity

Optimizing interrupt request handling ensures that hardware interrupts do not interfere with real-time processes. Tools like irqbalance can be configured or disabled to manually assign IRQs to specific CPU cores.

sudo apt-get install irqbalance
sudo irqbalance --oneshot


Alternatively, manually bind IRQs to less critical cores to minimize latency on real-time cores.

Disabling Unnecessary Services

Reducing the number of active services frees up system resources for real-time applications. Review and disable non-essential services using systemd.

systemctl list-units --type=service
sudo systemctl disable <service-name>


4. Managing CPU Affinity and Priority

Allocating CPU Resources for Real-Time Tasks

Isolating CPU Cores

Allocate specific CPU cores exclusively for real-time tasks to prevent contention. This can be done using the isolcpus parameter as previously mentioned, and by setting CPU affinity for real-time processes.

Setting Real-Time Scheduling Policies

Assigning real-time scheduling policies like SCHED_FIFO or SCHED_RR ensures that critical tasks receive appropriate CPU time.

sudo apt-get install real-time-scheduler
chrt -f 99 <command>


5. Disabling Hyper-Threading

Reducing Context Switching Overhead

Hyper-threading can introduce unpredictability in CPU performance due to shared resources between threads. Disabling it can lead to more consistent real-time performance.

Disable Hyper-Threading through BIOS/UEFI settings. The exact steps vary depending on the motherboard manufacturer.

6. Selecting a Lightweight Desktop Environment

Minimizing System Overhead

Using a lightweight desktop environment such as LXDE or XFCE reduces system resource consumption, leaving more CPU and memory available for real-time applications.

sudo apt-get install xubuntu-desktop


Choose the lightweight environment during login or set it as the default.

7. Monitoring and Profiling System Performance

Identifying and Addressing Bottlenecks

Latency Measurement Tools

Tools like cyclictest and RTLA help in measuring system latency and identifying performance issues.

sudo apt-get install rt-tests
sudo cyclictest -l100000 -m -S -p 98


Profiling Tools

Utilize perf, ftrace, and latencytop to profile and analyze system performance, helping to pinpoint and mitigate bottlenecks.

sudo apt-get install perf-tools-unstable
sudo perf record -a
sudo perf report


8. BIOS/UEFI Configuration

Optimizing Hardware Settings for Performance

Updating BIOS/UEFI Firmware

Ensure that your motherboard’s BIOS/UEFI firmware is up-to-date to benefit from performance enhancements and compatibility improvements.

Configuring Hardware Settings

Disable features that might interfere with real-time performance, such as Intel Turbo Boost, through the BIOS/UEFI settings.

9. Utilizing Specialized Middleware

Enhancing Real-Time Capabilities with Middleware

Depending on your application, employing real-time middleware like Xenomai or other specialized frameworks can provide additional guarantees and APIs for handling real-time tasks efficiently.

10. Iterative Testing and Refinement

Ensuring System Stability and Performance

Real-time performance optimization is an ongoing process. Regularly test system changes under realistic conditions, monitor performance, and make iterative adjustments to achieve the desired results.

---

Conclusion

Maximizing real-time performance on an Ubuntu system with an Intel CPU involves a multifaceted approach. By implementing a real-time kernel, optimizing CPU and power settings, fine-tuning system parameters, and carefully managing CPU affinity and priority, you can significantly enhance system responsiveness and predictability. Additionally, minimizing system overhead through lightweight desktop environments, disabling hyper-threading, and leveraging specialized middleware further contribute to achieving optimal real-time performance. Continuous monitoring and iterative testing ensure that the system remains stable and performs efficiently under real-world conditions.
