Python Code for Displaying a Network Graph

Comprehensive Guide to Visualizing Networks in Python

network graph visualization on computer screen

Key Highlights

Multiple Visualization Options: Use libraries such as NetworkX with Matplotlib for static graphs, Plotly for interactive plots, or Pyvis for web-based interactive networks.
Diverse Layout Algorithms: Leverage spring, circular, and random layouts to achieve effective visualization based on your graph’s structure.
Customization and Interactivity: Incorporate node attributes, edge weights, and community detection features for more informative and engaging graphs.

Introduction

Creating and visualizing a network graph in Python is an essential task in the fields of data science, social network analysis, and graph theory. Python offers a variety of libraries, each with its unique strengths. In this guide, we will cover the step-by-step process of generating a network graph using several libraries, including NetworkX, Matplotlib, Plotly, and Pyvis. You will find examples for static plotting as well as interactive visualization.

Using NetworkX with Matplotlib for a Static Graph

Overview

The combination of NetworkX and Matplotlib is a commonly used approach when you require a quick and straightforward visualization of a network graph. This method is well-suited for simple and static graphical representations.

Step-by-Step Explanation

1. Import the necessary libraries: NetworkX for graph creation and manipulation, and Matplotlib for visualization.
2. Create a graph object (undirected, by default).
3. Add nodes and edges representing entities and their connections.
4. Choose a layout algorithm (e.g., spring_layout) to determine the positions of nodes for optimal presentation.
5. Visualize the graph using nx.draw() with customized settings such as node color and size, then display the plot with plt.show().

Example Code with NetworkX and Matplotlib


# Import required libraries
import networkx as nx
import matplotlib.pyplot as plt

# Create a new graph object
G = nx.Graph()

# Add nodes, these may represent entities in your network
G.add_nodes_from(["A", "B", "C", "D", "E"])

# Add edges connecting the nodes
G.add_edges_from([("A", "B"), ("A", "C"), ("B", "D"), ("C", "D"), ("D", "E")])

# Choose a layout algorithm to position nodes. Spring layout is a popular choice.
pos = nx.spring_layout(G)

# Draw the graph using the chosen layout
nx.draw(G, pos, with_labels=True, node_color='skyblue', node_size=800, font_size=12, font_weight='bold', edge_color='gray')

# Provide a title for the plot
plt.title("Simple Network Graph using NetworkX and Matplotlib", fontsize=14)

# Display the graph
plt.show()

Using Plotly for Interactive Network Graphs

Overview

For enhanced interactivity, Plotly is an excellent alternative. Combining it with NetworkX allows the creation of dynamic and interactive network graphs. This approach is particularly useful when you need to explore different parts of a network by zooming, panning, and interacting with nodes.

Step-by-Step Explanation

1. Construct the network graph using NetworkX as usual.
2. Determine the layout of nodes using nx.spring_layout() or another algorithm.
3. Extract the positional data for edges and nodes, which involves creating lists to store coordinates.
4. Utilize Plotly’s Scatter traces to create both edge and node traces.
5. Combine these traces into a single figure and customize the layout including titles, axis settings, and interactivity options.

Example Code with Plotly


import networkx as nx
import plotly.graph_objects as go

# Create a new graph
G = nx.Graph()

# Add nodes and edges dynamically
G.add_nodes_from([1, 2, 3, 4, 5, 6])
G.add_edges_from([(1, 2), (1, 3), (2, 4), (3, 4), (4, 5), (5, 6), (1, 6)])

# Compute positions for nodes using spring_layout
pos = nx.spring_layout(G)

# Initialize lists for storing edge coordinates
edge_x = []
edge_y = []

# Extract coordinates for each edge
for edge in G.edges():
    x0, y0 = pos[edge[0]]
    x1, y1 = pos[edge[1]]
    edge_x += [x0, x1, None]
    edge_y += [y0, y1, None]

# Create the edge trace using Plotly Scatter
edge_trace = go.Scatter(
    x=edge_x, y=edge_y,
    line=dict(width=0.8, color='#888'),
    hoverinfo='none',
    mode='lines')

# Extract node coordinates
node_x = []
node_y = []
for node in G.nodes():
    x, y = pos[node]
    node_x.append(x)
    node_y.append(y)

# Create the node trace using Plotly Scatter
node_trace = go.Scatter(
    x=node_x, y=node_y,
    mode='markers',
    hoverinfo='text',
    marker=dict(
        size=12,
        color='lightblue',
        line=dict(width=2, color='darkblue')
    ))

# Assign node titles or descriptions for hover text
node_text = []
for node, adjacencies in G.adjacency():
    node_text.append(f"Node {node} has {len(adjacencies)} connection(s)")
node_trace.text = node_text

# Setup the overall layout for the figure
layout = go.Layout(
    title='Interactive Network Graph using Plotly',
    titlefont=dict(size=18),
    showlegend=False,
    hovermode='closest',
    margin=dict(b=20, l=5, r=5, t=40),
    xaxis=dict(showgrid=False, zeroline=False, showticklabels=False),
    yaxis=dict(showgrid=False, zeroline=False, showticklabels=False)
)

# Create the figure with both traces
fig = go.Figure(data=[edge_trace, node_trace], layout=layout)

# Render the interactive network graph
fig.show()

Using Pyvis for Web-Based Interactive Graphs

Overview

Pyvis is another powerful tool to transform your network graphs into interactive web pages. It leverages HTML to render the graphs, offering features like physics-based interactions, node filtering, and a customizable user interface.

Step-by-Step Explanation

1. Use NetworkX to create the graph structure or build the graph directly in Pyvis.
2. Convert the graph into a format recognized by Pyvis with the from_nx() function.
3. Customize the web-based graph with additional interactivity such as toggling physics and adding menus.
4. Save the output as an HTML file which can be viewed in any web browser.

Example Code with Pyvis


from pyvis.network import Network
import networkx as nx

# Create a graph using NetworkX
G = nx.Graph()

# Add nodes and edges to the graph
G.add_nodes_from([1, 2, 3, 4, 5])
G.add_edges_from([(1, 2), (1, 3), (2, 4), (3, 4), (4, 5)])

# Initialize a Pyvis network object
net = Network(notebook=False, height="600px", width="100%")

# Convert the NetworkX graph into a Pyvis graph
net.from_nx(G)

# Enable physics for dynamic interactions
net.toggle_physics(True)

# Optional: Add interactivity controls
net.show_buttons(filter_=['physics'])

# Save and display the interactive network graph as HTML
net.show("network_graph.html")

Comparative Summary of Visualization Libraries

Below is a table summarizing the key aspects of each library used for creating network graphs in Python:

Library	Visualization Type	Key Features
NetworkX + Matplotlib	Static	Simple setup; ideal for quick and straightforward plots; widely used in academic research.
NetworkX + Plotly	Interactive	Enables dynamic graph navigation; zoom, pan, and hover for detailed inspection; customizable traces.
Pyvis	Web-Based Interactive	User-friendly interface; physics-enabled interactions; easily viewable in web browsers; ideal for embedding.

Additional Considerations

Graph Layouts

The choice of layout algorithm significantly influences how clearly the network visualization communicates its structure:

Spring Layout: Uses a force-directed algorithm that models nodes as repelling particles and edges as springs; provides an organic distribution.
Circular Layout: Places nodes in a circle, ideal for symmetric graphs.
Random Layout: Places nodes randomly; used for preliminary explorations or when no specific structure is needed.

Node and Edge Customization

Tailor your visualizations by adjusting styles and including data-specific attributes such as:

Colors: Differentiate nodes or highlight communities.
Node Sizes: Reflect metrics like degree centrality.
Edge Styling: Include width, color, and opacity based on connection strength or weight.

Community Detection and Analysis

For a deeper understanding of your network, consider integrating community detection algorithms (e.g., greedy modularity) that partition the graph into clusters. This can be coupled with color-coding to make community structures visually intuitive, especially important when dealing with large or real-world datasets.

Conclusion

In this guide, we have walked through several methods to create and display network graphs in Python, ranging from static plots with Matplotlib to interactive displays with Plotly and Pyvis. Each approach comes with its benefits:

The NetworkX and Matplotlib combination is excellent for generating quickly interpretable static graphs, whereas Plotly brings enhanced interactivity suitable for exploratory data analysis. Pyvis stands out for web-based interactive visualizations that can be integrated into dashboards and web pages. Additionally, the choice of layout, node properties, edge representation, and community detection algorithms further enhances your ability to communicate complex network structures effectively.

Whether you are analyzing social networks, biological systems, or any interconnected data, these Python-based visualization methods provide a flexible and powerful toolkit. Experimenting with these libraries and customization options will help you not only display network graphs but also uncover underlying patterns and insights.
